Shortening clutch with locking UGCV, Green Pin®

The Green Pin® Shortening Clutch with Lock is a grade 10 shortening clutch with locking pin. The shortening clutch is an essential part of chain slings, used to shorten the length of a chain leg and prevents instability of the load. The clutch compared to the shortening hook makes a straight pull possible. This shortening clutch is available with a locking system, designed to prevent accidental disengagement of the chain. The Green Pin® Shortening Clutch with Lock is available in a range to suit 6 mm up to 20 mm grade 10 chain.

Certification: at no extra charge this product can be supplied with a works certificate, a 3.1 material certificate and/or EC Declaration of Conformity

  • Material: alloy steel, quenched and tempered
  • Temperature range: -40°C up to +200°C
  • Finish: painted blue
  • Safety factor: 4:1
  • Grade: 10
