General:
Hand pallet truck, stainless steel version model HU 20-115 VATP PROLINE. Capacity 2000 kg. For the professional transportation of palletised goods in corrosive areas.

- Low maintenance high performance hydraulic pump with hard chromium plated piston and pressure relief valve. Hydraulic unit made of V4A – 316 stainless steel.
- Frame, adjustable connecting rods, bolts and the torsion tube are made of high quality V4A – 316 stainless steel.
- Steering angle of 105 degree to each side for easy handling in confined spaces.

  • Features: - Ergonomic safety control handle for one-hand operation of lifting, driving and lowering.
Product Image 1
Product Image 2
Select a row from the table below, then click the add to quote button
Part Code Type Wheels Capacity
kg
h3
mm
l
mm
B1
mm
h14
mm
h13
mm
e
mm
Weight
kg
CAD
040005740 HU 20-115 VATP PA/PA 2 000 115 1 150 540 1 200 85 160 86
PA (polyamide) / PUR (polyurethane) / VG (solid rubber)
