General:
Scissor pallet truck with manual-hydraulic lift model HU HS 10 A. Capacity 1000 kg, fork height max. 800 mm. A combination of hand pallet truck and elevating platform for the transport and raising of palletised loads to various departments

- Lowering speed can be finely metered for sensitive lowering of the load.
- One-stage hydraulic for increased robustness.
- Quick-lift for loads up to 250 kg.
- Overload protection by pressure relief valve.
- Safety supports guarantee sure standing when the forks are raised.
- Low noise and smooth running with standard tyres: steer rollers and load rollers – polyurethane.

  • Features: - Safety control handle with the functions: – Quick-lift – lifting – lowering.
Product Image 1
Product Image 2
Select a row from the table below, then click the add to quote button
Type Wheels Capacity
kg
wheels # h3
mm
B5
mm
l
mm
b 1/2
mm
C
mm
h14
mm
h13
mm
e
mm
s
mm
l1
mm
m2
mm
Wa
mm
Ast
mm
Weight
kg
CAD
HU HS 10 A PUR/PUR 1 000 2/2 715 540 1 150 540 600 1 235 85 160 50 1 650 35 1 440 1 900 140
PA (polyamide) / PUR (polyurethane) / VG (solid rubber)
