ZHR chain block

General:
Heavy-duty hand chain block for loads from 500 up to 20,000 kg.

Technical characteristics:
Specification identical to those for the standard version of the VHR except for the following features :
- Overload limiter is standard equipment.
- 3 meters standrad lift. Hand chain is 0.5 meters less than lift chain.
- Four-bearing lifting mechanism.
- High strength grade 80 alloy steel load chain with corrosion-resistant galvanized (complies with standard EN 818, safety factor 4).
- Load chain Made in Europe.
- Galvanized hand chain made in Europe.
- Upper and lower alloy steel ISO hooks with safety latches.
- Weston-type load brakes.
- Offshore high-resistance RAL 7021 powder coating, 220 μ thick.
- Delivered with CE certificate, and hook and chain certificate.

Optional:
A wide range of options is available for this hand chain block. For example:
- ZHR with stainless steel load and hand chain.
- Chain bag.
- ZHR HPN with normal headroom.
- ZHR HPR with short headroom trolley.
