General:
Range of hand spurgear winches from 300 to 2750 kg, models with painted, galvanized or stainless steel frame.
Comply with Machines Directive 2006/42/EC. Developped and manufactured in accordance with standard NF E N 13157.
Use:
•Lifting or pulling/hauling operation
•Flat
•Industry
•Auditoriums, theatre scenery
•Water treatment, water dams
•Sports rooms
•Hanging chandeliers...
Technical characteristics:
•Mechanical parts machined and protected by cataphoresis.
•Stainless steel ratchet spring.
•Straight-cut gears.
•Automatic brake made of composite materials.
•Disengageable drum, no load only, associated with a failsafe system in the rope wind direction (patented).
•Reduction system fully protected by a metal or plastic cover providing maximum safety.
•Ergonomic and removable crank handle with rotating grip. This crank arm can be adjusted to minimise effort according to the loads.
•Captive crank adjusting knob.
•Finition : galvanized, painted or stainless steel frame
