General:
Hand pallet truck with weighing system model HU W-20 S SILVERLINE. Capacity 2000 kg. For transportation and weighing of palletised goods and box pallets.
Features:
- Ergonomic safety control handle for one-hand operation of lifting, driving and lowering.
- Ergonomic rubber control handle for safe handling.
- Measuring range from 0 up to 2000 kg in 1 kg steps.
- Easy to read LCD display.
- Accuracy +/- 0.25% of the end value.
- The readings start at 1.0 kg.
- The weighing system is calibrated at the factory.
- The system is designed for simple weighing jobs, such as batching or filling processes.
- Low maintenance hydraulic pump with hard chromium plated piston and pressure relief valve.
- Frame and forks in robust steel construction, adjustable connecting rods, especially hardened axles and the high quality powder coating ensure a long life expectancy.
- Steering angle of 105 degree to each side for easy handling in confined spaces.
Scope of delivery:
- 4 x 1.5 V batteries

Product Image 1
Product Image 2
Select a row from the table below, then click the add to quote button
Part Code Type s
mm
Capacity
kg
l1
mm
wheels # m1
mm
h2
mm
h3
mm
B3
mm
l
mm
B1
mm
C
mm
h14
mm
h13
mm
e
mm
Weight
kg
CAD
040016431 HU W-20 S 50 2 000 1 580 2/4 35 110 195 210 1 150 570 600 1 210 85 180 129
PA (polyamide) / PUR (polyurethane) / VG (solid rubber) /Ambient temperature: -10°C up to +40°C

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.

Get CAD
Download
