Wire rope clip Green Pin® G-6240

Home / Products / LIFTING EQUIPMENT / Clamps & grabs / Wire rope clips & clamps / Green Pin Wire Rope Clip G-6240

If you are looking for high quality wire rope clips then the Green Pin G-6240 clips are the right choice. The bridge is made of drop forged high tensile steel SAE 1045 and the U-bolt of SAE 1015.
These Green Pin clip are galvanized.

Material: Bridge: drop forged high tensile steel SAE 1045. U-bolt: SAE 1015.
Marking: According to standard
Finish: Hot dip galvanized. Nuts for diameter bow 5 and 6 mm are electro-galvanized.
Standard: EN 13411-5

Green Pin Wire Rope Clip G-6240

Select a row from the table below, then click the add to quote button

Part Code	Diameter rope mm	Weight
10.17CLGRP04	4	2
10.17CLGRP05	5	4
10.17CLGRP06	7	8
10.17CLGRP08	8	14
10.17CLGRP10	10	19
10.17CLGRP11	11	31
10.17CLGRP13	13	34
10.17CLGRP15	15	36
10.17CLGRP16	16	45
10.17CLGRP20	20	68
10.17CLGRP22	22	108
10.17CLGRP26	26	113
10.17CLGRP30	30	140
10.17CLGRP34	34	207
10.17CLGRP36	36	234
10.17CLGRP40	40	266
10.17CLGRP42	42	329
10.17CLGRP46	46	441
10.17CLGRP52	52	603
10.17CLGRP58	58	707
10.17CLGRP65	65	806
10.17CLGRP72	72	1 000
10.17CLGRP78	78	1 440

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.

Get CAD

Download
