Green Pin

Certification: at no extra charge this product can be supplied with a works certificate, a 3.1 material certificate and/or EC Declaration of Conformity

  • Material: alloy steel, quenched and tempered
  • Finish: painted blue
  • Safety factor: 4:1
  • Grade: 10
Select a row from the table below, then click the add to quote button
Part Code WLL
ton
For chain ø
mm
a
mm
b
mm
c
mm
d
mm
e
mm
f
mm
g
mm
Weight
kg
CAD
11.09UMP6 1,4 6 84 8 7 64 33 109 55 0,14
11.09UMP8 2,6 8 100 10 9 77 40 132 69 0,28
11.09UMP10 4 10 125 13 12 97 50 165 84 0,63
11.09UMP13 6,8 13 161 16 15 125 66 213 110 1,4
11.09UMP16 10,3 16 198 20 19 154 84 262 140 2,72
