General: De PA 18 F 2 is the all-round 2-stage foot pump.

Features & Benefits:
- Ergonomic design.
- Light weight; easy to carry and operate.
- Low operating force required; minimal user effort.
- Soft-grip handles; more comfort and grip.
- Anti-slip rubber underneath; pump is stable and does not shift.
- Pump handle lock; easy and sfe to carry
- Service- and maintenance friendly; Easy access to and replacement of technical parts
without removing the oil tank.
- High oil output; quicker action.
- Accurately adjustable pressure release valve; load can be lowered safely and with extreme control.
- Integrated gauge connection on the pump block; No extra component needed if pressure
gauge is used. Gauge can be directly mounted at an angle of 45 degrees.
- Oil level glass in the tank; easily check the oil level in both horizontal and vertical position.
- Integrated filler funel; top up oil easily and quickly without extra accessoiries.
- Push & Unlock pump handle lock; unlocking is quick and easy with one push on the pump handle.

Product Picture 1
Product Picture 2
Select a row from the table below, then click the add to quote button
Size Model max. working pressure
max. operating force kg oil capacity cc connection A
724 PA 18 F2 720 / 72 37 1 900 3/8"NPT female 724 169 167 8,3

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
