General:
Hand pallet truck modell HU 25-115 TS SILVERLINE model HU 25-115 ES SILVERLINE. Capacity 2500 kg. For the professional transportation of palletised goods and box pallets under demanding conditions.

- Ergonomic rubber control handle for safe handling.
- Low maintenance hydraulic pump with hard chromium plated piston.
- Frame and forks in robust steel construction, adjustable connecting rods, especially hardened axles and the high quality powder coating ensure a long life expectancy.

  • Features: - Ergonomic safety control handle for one-hand operation of lifting, driving and lowering.
Product Image 1
Product Image 2
Select a row from the table below, then click the add to quote button
Part Code Type Wheels Capacity
kg
wheels # h3
mm
B3
mm
l
mm
B1
mm
C
mm
h14
mm
h13
mm
e
mm
s
mm
l1
mm
Wa
mm
Ast
mm
m1
mm
Weight
kg
CAD
034527101 HU 25-115 TS VG/PUR 2 500 2/4 115 1 150 540 600 1 230 85 160 48 1 555 1 275 1 793 37 68
034527130 HU 25-115 TS PA/PA 2 500 2/4 115 220 1 150 540 600 1 200 85 160 45 1 535 1 330 1 815 40 68
034527184 HU 25-115 TS PUR/PA 2 500 2/4 115 220 1 150 540 600 1 200 85 160 45 1 535 1 330 1 815 40 68
034527100 HU 25-115 TS VG/PA 2 500 2/4 115 220 1 150 540 600 1 230 85 160 48 1 555 1 330 1 793 37 70
034527108 HU 25-115 TS PUR/PUR 2 500 2/4 115 220 1 150 540 600 1 200 85 160 45 1 535 1 330 1 815 40 79
034527106 HU 25-115 ES VG/PUR 2 500 2/2 115 1 150 540 600 1 200 85 160 45 1 535 1 330 1 815 40 84
PA (polyamide) / PUR (polyurethane) / VG (solid rubber)

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
