General:
- Max. working pressure: 720 bar/ 72 Mpa
- Acting type: single
- Return type: gravity
- Compact
- Usable in all positions
- Protected against ejection of plunger
Standard supplied with:
- High Flow female coupler A 118
Available on request:
- Cylinders manufactured in conformity with customer specifications
- Collar thread
- Base mounting holes
- Material: steel
