General: Vari Pump AIR - 1 stage - 8 bars.


- Protected against pressure drop by pressure-controlled non-return valve.



Available on request:
- Larger oil tank.
- Other voltages/ frequencies

  • Features: - Safe; in case of a power failure, the oil pressure is maintained.
  • Note: Excluding single-acting or double-acting control valve.
    Product Image 1
    Product Image 2
    Product Brand Logo
    Select a row from the table below, then click the add to quote button
    Model max. working pressure
    bar/Mpa
    oil capacity cc Engine L thread size W
    mm
    H
    mm
    Weight
    kg
    12 S 6 SA 720 / 72 6 000 air- 8 bars - 3.0 kW 400 300 348 33
    12 S 12 A 720 / 72 12 000 air- 8 bars - 3.0 kW 400 300 448 41
    18 S 12 A 720 / 72 12 000 air- 8 bars - 3.0 kW 400 300 448 42
    12 S 25 A 720 / 72 25 000 air- 8 bars - 3.0 kW 500 380 448 60
    18 S 25 A 720 / 72 25 000 air- 8 bars - 3.0 kW 500 380 448 62
    12 S 50 A 720 / 72 50 000 air- 8 bars - 3.0 kW 500 380 583 89
    18 S 50 A 720 / 72 50 000 air- 8 bars - 3.0 kW 500 380 583 91
