General:
- Max. working pressure: 720 bar/ 72 Mpa
- Acting type: double
- Return type: hydraulic
- compact and lightweight
- Usable in all positions
- Protected against ejection of plunger
- Screw-on saddle. Prevents damage to the plunger and is easy to replace.
- Standard fixing thread (designed for maximum cylinder load) on plunger head, on cylinder housing and cylinder bottom
Standard supplied with:
- High Flow female coupler A 118
- flat saddle
Available on request:
- Cylinders manufactured in conformity with customer specifications
- Material: steel
- Note: Consult the user manual before fitting cylinder accessories to these cylinders. The maximum working pressure and total construction length is restricted when using cylinder accessories!
